ADP-20/PCI 20-pin Connector Extender for PCI Card with Flat Cable
Dual 20-pin to 20-pin connector extender for PCI card, supplied with one CA-2002 20-pin flat cable set (20 cm). RoHS compliant.
- Extends a dual 20-pin flat cable connection
- Designed for PCI card connections
- Includes CA-2002 flat cable set, 20-pin, 20 cm (2 cables)
- RoHS compliant
- Part of the DAQ daughter board accessory range
26,00 € pro Stück
| 1–9 Stück | 26,00 € | |
|---|---|---|
| 10–30 Stück | 25,00 € | −4 % |
| ab 31 Stück | 24,00 € | −8 % |
Produktinformationen "ADP-20/PCI 20-pin Connector Extender for PCI Card with Flat Cable"
ADP-20/PCI CR is a 20-pin to 20-pin connector extender for PCI card wiring. It carries a dual 20-pin flat cable connection over a longer run, so the card can be reached from a more convenient location.
The kit includes one CA-2002 flat cable set, 20-pin, 20 cm long, supplied as two cables. This lets you start wiring straight away without sourcing a matching cable separately.
The extender is RoHS compliant. It belongs to the DAQ daughter board accessory range, so it suits engineers building or servicing data acquisition setups that use PCI cards.
| Product type: | Connector extender |
|---|---|
| Interface: | 20-pin to 20-pin |
Technische Daten
| Mechanical | |
|---|---|
| Dimensions (mm) | 114 mm x 102 mm |
| Environment | |
| Operating Temperature | 0~ +60 °C |
| Storage Temperature | -30 ~ +80 °C |
| Humidity | 10% ~ 90%, no condensing |
Technische Daten laut Hersteller. Änderungen vorbehalten.
