CL-220-E PM1/PM2.5/PM10 Data Logger Module, RS-485 & Ethernet PoE
Data logger module for PM1, PM2.5, PM10, temperature, humidity and dew point, storing up to 450,000 time-stamped records with DCON, Modbus RTU/TCP and MQTT support.
- Records PM1, PM2.5, PM10, temperature, humidity and dew point with date and time stamps
- Stores up to 450,000 downloadable records
- RS-485 and Ethernet interfaces with PoE support on the Ethernet port
- Supports DCON, Modbus RTU, Modbus TCP and MQTT protocols
- Web-based configuration plus Windows software utility and iOS and Android apps
- Relay output: 1 x Form A, SPST, 30 VDC @ 16 A or 250 VAC @ 16 A
366,00 € pro Stück
| 1–9 Stück | 366,00 € | |
|---|---|---|
| 10–30 Stück | 355,00 € | −3 % |
| ab 31 Stück | 348,00 € | −5 % |
Produktinformationen "CL-220-E PM1/PM2.5/PM10 Data Logger Module, RS-485 & Ethernet PoE"
CL-220-E CR is a data logger module for monitoring particulate matter alongside temperature, humidity and dew point. Each reading is stored with date and time stamps in internal memory of up to 450,000 records, which can be downloaded for trend analysis, compliance records or fault investigation.
The module connects over RS-485 or Ethernet, with PoE available on the Ethernet port, so it can be added to existing HMI, SCADA or distributed control systems. DCON, Modbus RTU, Modbus TCP and MQTT are supported for polling and IoT-style publishing. A relay output allows it to drive an alarm or an indoor air quality (IAQ) device when set thresholds are reached.
Configuration is handled through a web-based interface, with a Windows software utility and iOS and Android apps included for setup, live monitoring and log downloads. Logs can be exported to CSV for use in standard spreadsheet or analysis software.
Applications
- Transportation of food or pharmaceuticals
- Food and beverage industry (HACCP)
- Blood stations and pharmacies
- Building and energy management
- Warehouse management
- Museums, archives and galleries
- Indoor or underground parking lot air quality monitoring
| Product type: | Data logger module |
|---|---|
| Interface: | Ethernet, RS-485 |
| Protocol: | DCON, Modbus RTU, Modbus TCP, MQTT |
| Relay outputs: | 1 |
| Ports: | 2 |
| PoE: | Yes |
| Power input: | +12 ~ +48 VDC |
| Operating temperature: | 0 ~ 50°C |
| Mounting: | Ceiling/Wall |
| Housing: | Ø 150 x 53 mm |
Technische Daten
| System | |
|---|---|
| Alarm | PM1/PM2.5/PM10/RH/Temperature |
| Real Time Clock | Yes |
| Data Logger | Yes, up to 450,000 records |
| Temperature Measurement | |
| Range | -10 ~ +50°C |
| Resolution | 0.1°C |
| Accuracy | ±0.6°C |
| Life Time | 10 years |
| Humidity Measurement | |
| Range | 0 ~ 100% RH, Non-condensing |
| Resolution | 0.1% RH, Non-condensing |
| Accuracy | ±5% RH, Non-condensing |
| Life Time | 10 years |
| Dew Point | |
| Range | Calculated using temperature and relative humidity |
| Resolution | 0.1°C |
| PM1/PM2.5/PM10 Measurement | |
| Range | 0 to 1,000μg/m3 ( Laser Type) |
| Resolution | 1μg/m3 |
| Accuracy | ± 10% of FSR. |
| Response Time | 1 seconds |
| Warm-up Time | 20 seconds |
| Life Time | 5 years, Customer has to replace the filter patch. |
| Particle | |
| Sizes | 0.3μm, 0.5μm, 1μm, 2.5μm, 5μm, 10μm |
| Relay Output | |
| Channels | 1 x Form A, SPST 30 VDC @ 16 A or 250 VAC @ 16 A |
| Ethernet | |
| Ports | 10/100 Base-TX, 8-Pin RJ-45 x1 (Auto-negotiating, Auto-MDI/MDIX, LED indicators) |
| COM Ports | |
| Ports | 1 x RS-485 1 x Ethernet |
| Protocol | DCON and Modbus/RTU (RS-485) Modbus TCP and MQTT (Ethernet) |
| Power | |
| Consumption | Non-PoE: 2.4 W (Max.) PoE: 2.6 W (Max.) |
| Powered from Terminal Block | +12 ~ +48 VDC |
| Mechanical | |
| Dimensions (mm) | Ø 150 x 53 (Ø x H) |
| Installation | Ceiling Mounting/Wall Mounting |
| Ingress Protection Rating | IP20 |
| Environment | |
| Operating Temperature | 0 ~ 50°C |
| Storage Temperature | -30 ~ +75°C |
| Humidity | 10 ~ 90% RH, Non-condensing |
Technische Daten laut Hersteller. Änderungen vorbehalten.
