I-7188XB-512 Serial PAC with 80188-40 CPU, MiniOS7 and X-board I/O Expansion
Compact serial PAC with an 80188-40 CPU, MiniOS7 and C-language development, offering RS-232/RS-485 ports, 1 dry contact input, 1 open-collector output and an X-board expansion interface.
- 80188 CPU at 40 MHz with built-in MiniOS7 and C-language development tools
- 512 KB flash, 512 KB SRAM, 2 KB EEPROM and 31 bytes NVRAM
- 1 dry contact digital input and 1 open-collector digital output (+30 VDC max., 100 mA)
- RS-232/RS-485 and RS-485 serial ports, up to 115200 bps
- I/O expansion bus with X-board interface
- Real-time clock, watchdog timer and 64-bit hardware serial number
242,00 € pro Stück
| 1–9 Stück | 242,00 € | |
|---|---|---|
| 10–30 Stück | 235,00 € | −3 % |
| ab 31 Stück | 230,00 € | −5 % |
Produktinformationen "I-7188XB-512 Serial PAC with 80188-40 CPU, MiniOS7 and X-board I/O Expansion"
The I-7188XB-512 is a palm-size serial programmable automation controller for embedded control in harsh industrial environments. It suits designs where a PC or PLC would be too large, too costly or too demanding, and it runs the built-in MiniOS7 real-time operating system with programs written in C.
Built around an 80188 CPU running at 40 MHz, the controller provides 512 KB of flash and 512 KB of SRAM, plus 2 KB of EEPROM and 31 bytes of NVRAM for retained data. A real-time clock, a watchdog timer and a 64-bit hardware serial number support reliable, traceable operation. The I/O expansion bus accepts X-board modules for extending the I/O.
This ordering code is the blue-cover variant (CR suffix). Its built-in I/O comprises one dry contact input and one open-collector output rated up to +30 VDC and 100 mA. Communication is handled by one RS-485 port and one RS-232/RS-485 port at up to 115200 bps. The unit is DIN-rail mounted, powered from +10 to 30 VDC and rated for -25 to +75 °C operation.
Applications
- Replacing PC or PLC devices in harsh industrial environments
- Palm-size embedded control systems
- OEM products using the controller as a processor core component
| Product type: | Serial PAC |
|---|---|
| Interface: | RS-232, RS-485 |
| Digital inputs: | 1 |
| Digital outputs: | 1 |
| Ports: | 2 |
| Power input: | +10 ~ 30 VDC |
| Operating temperature: | -25 ~ +75 °C |
| Mounting: | DIN-rail |
Technische Daten
| Software | |
|---|---|
| OS | MiniOS7 |
| Development | C Language |
| CPU Module | |
| CPU | 80188, 40 MHz or compatible |
| 64-bit Hardware Serial Number | Yes |
| EEPROM | 2 KB |
| Flash | 512 KB |
| NVRAM | 31 Bytes |
| SRAM | 512 KB |
| Real Time Clock | Provide seconds, minutes, hours, day of week, month, year |
| Watchdog Timer | Yes |
| LED Indicators | |
| Status | 1 x System |
| Digital Input | |
| Channels | 1 |
| Type | Dry Contact |
| ON Voltage Level | Close to GND |
| OFF Voltage Level | Open |
| Digital Output | |
| Channels | 1 |
| Type | Open Collector |
| Load Voltage | +30 VDC max. |
| Load Current | 100 mA |
| I/O Expansion | |
| I/O Type | X-board |
| COM Ports | |
| Ports | 1 x RS-485, 1 x RS-232/RS-485 |
| Baud Rate | 115200 bps Max. |
| Power | |
| Input Range | +10 ~ 30 VDC |
| Consumption | 2.0 W |
| Mechanical | |
| Dimensions (mm) | 72 x 123 x 33 (W x H x D) |
| Installation | DIN-Rail Mounting |
| Environment | |
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -30 ~ +80 °C |
| Humidity | 5 ~ 90 %, Non-condensing |
Technische Daten laut Hersteller. Änderungen vorbehalten.
