LP-2241MX-4GC 4G Linux PAC with Cortex-A8 CPU and 2 LAN Ports
4G Linux-based PAC with a 1 GHz Cortex-A8 CPU, dual Gigabit Ethernet, four serial ports and an XV-Board I/O expansion bus for cellular data applications.
- 1 GHz Cortex-A8 CPU with 512 MB DDR3 RAM and 512 MB Flash
- Linux kernel 3.2.14 with real-time capability
- Integrated tri-band 4G module with 4G modem for remote data transfer
- Dual 10/100/1000M Ethernet ports (RJ-45)
- Four serial ports: RS-232/485, with two RS-485 ports isolated at 2500 VDC
- XV-Board I/O expansion bus
Dieser Artikel wird je Auftrag kalkuliert. Nennen Sie uns die Menge, wir antworten mit Preis und Lieferzeit.
Angebot anfragen
Nicht mehr verfügbar
Produktinformationen "LP-2241MX-4GC 4G Linux PAC with Cortex-A8 CPU and 2 LAN Ports"
LP-2241MX-4GC CR is a Linux-based programmable automation controller built around a 1 GHz Cortex-A8 processor, running Linux kernel 3.2.14. It suits engineers who need a compact controller that combines local control with remote data transfer over cellular networks, with real-time capability for time-critical tasks.
An integrated tri-band 4G module with a 4G modem supports WCDMA, TD-SCDMA, CDMA2000, FDD and TDD LTE, and GSM/GPRS connectivity. This allows live or packet data to be sent from remote instruments, meters or control systems. Two 10/100/1000M Ethernet ports, four serial ports (RS-232/485) and an XV-Board I/O expansion bus add connectivity and I/O flexibility.
The unit provides 512 MB RAM and 512 MB Flash, a microSD socket, FRAM non-volatile memory, a real-time clock and dual watchdog timers. A metal case and DIN-rail or optional wall mounting suit installation in industrial cabinets. Web, SFTP and SSH services are supported, and a LinPAC SDK with a GCC-based toolchain is provided for application development.
Applications
- Remote data acquisition over 3G/4G cellular networks
- Multi-serial device communication
- Ethernet-based control and monitoring
- SNMP-managed network devices
- Metering and remote instrument data collection
| Product type: | PAC |
|---|---|
| Interface: | Ethernet, RS-232/485 |
| Ports: | 2 LAN, 4 serial, 2 USB |
| Isolation: | 2500 VDC (RS-485) |
| Power input: | +12 ~ +48 VDC |
| Operating temperature: | -25 ~ +75 °C |
| Mounting: | DIN-rail, Wall |
| Housing: | Metal |
Technische Daten
| Software | |
|---|---|
| OS | Linux Kernel 3.2.14 |
| Service | SFTP server, Web server, SSH |
| SDK | LinPAC SDK (GCC based toolchain and LinPAC Libraries) |
| Main Unit | |
| CPU | Cortex-A8, 1 GHz |
| 64-bit Hardware Serial Number | Yes, for Software Copy Protection |
| System Memory | 512 MB DDR3 SDRAM |
| Storage | • Flash 512 MB • microSD socket with a 4 GB microSD card (support up to 32 GB microSDHC card) |
| Non-Volatile Memory | FRAM 64 KB |
| Real Time Clock | Yes (Provide seconds, minutes, hours, day of week, month, year) |
| Watchdog Timer | Yes, Dual Watchdog Timer |
| Display | |
| Signal | VGA (Analog RGB) |
| Resolution | Up to 1280 x 1024 |
| LED Indicators | |
| Status | 1 x 4G 1 x Power 1 x Run 3 x Programmable |
| 3G System | |
| Data Transmission Rate | DC-HSPA+ Download: Max. 42 Mbps, Upload: Max 5.76 Mbps; TD-SCDMA Download: Max. 4.2 Mbps, Upload: Max 2.2 Mbps; CDMA2000 EVDO Download: Max. 14.7 Mbps; Upload: Max 5.4 Mbps |
| Frequency Band | WCDMA 900/2100 MHz, TD-SCDMA 1900/2100 MHz, CDMA2000 (BC0) 800 MHz |
| 4G System | |
| Data Transmission Rate | Download Max 100 Mbps/Upload Max 50 Mbps |
| Frequency Band | FDD LTE: B1/B3/B8, TDD LTE: B38/B39/B40/B41 |
| GPS/GNSS | |
| Channels | 32 |
| Protocol | NMEA 0183 |
| GSM | |
| Data Transmission Rate | Downlink transfer: Max. 85.6 kbps, Uplink transfer: Max 42.8 kbps |
| Frequency Band | GSM: 850/900/1800/1900 MHz |
| GPRS Connectivity | GPRS class 12/10, GPRS station class B |
| I/O Expansion | |
| I/O Type | XV-board |
| HMI | |
| Buzzer | Yes |
| Rotary Switch | Yes (0 ~ 9) |
| Ethernet | |
| Ports | 2 x RJ-45, 10/100/1000 Base-TX |
| COM Ports | |
| Ports | 1 x RS-232 (Console, Non-isolated) 1 x RS-232, Non-isolated 2 x RS-485 (2500 VDC, Isolated) |
| USB | |
| Ports | 2 |
| Specification | USB 2.0 (Host) |
| Power | |
| Input Range | +12 VDC ~ +48 VDC |
| Consumption | 4.8 W |
| Mechanical | |
| Casing | Metal |
| Dimensions (mm) | 35 x 167 x 119 (W x L x H) |
| Installation | DIN-Rail or Wall Mounting (optional) |
| Environment | |
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -40 ~ +80 °C |
| Humidity | 10 ~ 95% RH, Non-condensing |
Technische Daten laut Hersteller. Änderungen vorbehalten.
